OCTG casing and tubing

April 14, 2020

Types of casing threads used

Casing and tubing strings are the main parts of the well construction. All wells drilled for the purpose of oil or gas production (or injecting materials into underground formations) must be cased with material with sufficient strength and functionality.Oil country tubular goods (OCTG) is a family of seamless rolled products consisting of drill pipe, casing and tubing subjected to loading conditions according to their specific application. In oilfield tubing and casings, thread profiles are designed and manufactured in order to provide superior hydraulic seals between the equipment and pipes. There are several types of Casing Threads used; they include: Ⅰ.Buttress […]
December 22, 2016
api 5ct octg coupling

API 5CT OCTG pipe Couplings, 4-20 inches,threaded end, R1,R2,R3

Abter is a professional industrial pipe manufacturer based in China, we have been producing pipe for a variety of applications, and covering areas of pipe manufacturing, exporting and trading. Abter offers a wide variety Couplings for Casing, Tubings and Line Pipes. The Tubing / Casing and Line Pipe Couplings are manufactured to meet the requirements of API 5CT and API 5L certifications respectively. A coupling is a device used to connect two shafts together at their ends for the purpose of transmitting power. Couplings do not normally allow disconnection of shafts during operation, however there are torque limiting couplings which […]
December 13, 2016
api 5ct casing and tubing

API 5CT well casing steel pipes, J55 K55 N80 L80 oil casing pipes

API 5ct Tubing: Tubings are used as pipe to transport crude oil or natural gas from layer of the oil to surface, can bear better pressure during oil or gas production, and have smaller diameters. API 5ct Well Casing pipe: Casings are used for fixing the well wall or down hole, which have wide diameters, can be divided into conductor casings, technical casings and Oil casings. dimensions of  API 5CT casing 1. Steel grade:J55, K55, L80, N80, P110 2. outside diameters:4 1/2″, 5″, 5 1/2″, 6 5/8″, 7″, 7 5/8″, 9 5/8″, 10 3/4″, 13 3/8″, 16″, 18 5/8″, 20″ 3. Wall […]
December 8, 2016
API 5ct j55 casing and tubing

API 5CT J55 Seamless oil Casing and tubing,OTCG casing R3, 13-3/8 Inch

 API 5CT casing and tubing 1)Sizes (O.D. x W.T): from 2 3/8″-4 1/2″ X 0.167″-0.63″ 2)Standard: API SPEC 5CT. 3)Steel Grade: J55, K55, N80,L80-1,P110 Casing and Coupling API 5CT GRADE: J55/K55/N80-1/N80-Q/L80/P110/P110 HC Outside diameter(mm) Wall thickness(mm) Φ114.3 5.69 6.35 7.37 8.56 Φ127 7.52 9.19 11.1 12.14 12.7 Φ139.7 6.98 7.72 9.17 10.54 12.7 14.27 15.87 Φ168.28 7.32 8.94 10.59 12.06 Φ177.8 8.05 9.19 10.36 11.51 12.65 13.72 Φ219 Above 8 Φ244.5 Above 8 Φ273 Above 8 B. Tubing and Coupling API 5CT GRADE: J55/K55/N80-1/N80-Q/L80/P110/P110 HC Outside diameter(mm) Wall thickness(mm) Φ60.33 4.24 4.83 6.45 7.49 8.53 Φ73.03 5.51 7.01 7.82 8.64 9.96 Φ88.9 […]
