Low, ambient and high temperature service

December 26, 2018

A333 Grade 6 Low Carbon Steel in Pipelines – Microstructural Characterization and Hardness Properties

M. N. Ervina Efzan*, S. Kesahvanveraragu, J. Emerson   1.0 INTRODUCTION 1.1 Offshore Pipeline Material Pipelines in offshore platform are made up of various types of materials. Selection of material relies upon certain considerations such as cost, functional requirement, operating conditions of pressure and temperature, corrosion rate and so forth [1-2]. Since there are varieties of pipelines in offshore platform, material selection and those considerations are highly required. In offshore industry, metal is the highly used material that can be assorted into ferrous and non-ferrous metals [1-3]. Metals containing iron (Fe) as their premier composition are known as ferrous metals, whereas metals containing other elements are termed as non-ferrous […]
October 10, 2018

DIN17175 seamless Heat Exchanger Tubes

DIN 17175 seamless steel pipe is used in boiler installations, high-pressure pipelines and tank construction and special machinery for both high temperature and high-pressure devices. And it is widely used in the manufacture of structural parts and mechanical parts, such as drill pipe, automobile transmission shaft, self frame as well as the construction of the steel scaffolding. Steel Grade: St37, St44, St45, St52, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, Standard Grade Chemical Composition C Si Mn P≤ S≤ Cr Mo DIN17175 St35.8 ≤ 0.17 0.10~0.35 0.40~0.80 0.030 0.030 / / St45.8 ≤ 0.21 0.10~0.35 0.40~1.20 0.030 0.030 / / 15Mo3 0.12~0.20 0.10~0.35 0.40~0.80 0.030 0.030 / 0.25~0.35   […]
March 17, 2018

Seamless steel pipes for high temperature and pressure – Grade, Standard, Application ,Size

Seamless high-temperature tubes and furnace tubes suitable for use in applications with temperatures above 500ºC (932ºF). The ABTERSTEEL program of high-temperature tubes includes a wide range of austenitic stainless steels and nickel alloys as well as iron-chromium-aluminium (FeCrAl) alloys, which can be used at temperatures up to 1250ºC (2280ºF). Steel Grade: 20G、20MnG、25 MnG、20 MOG、12CrMoG、15 CrMoG、14Cr1MoG、12 Cr2MoG、12Cr1MovG、1Cr5Mo、 1Cr9Mo1、 12Cr2MoWVTiB、 07Cr2MoW2vNbB、 15NiCuMoNb5、 10Cr9Mo1VNbN、 10Cr9MoW2vNBN、 1Cr18Ni9、 0Cr18Ni11Nb、 0Cr25Ni20、 00Cr17Ni14Mo2、 0Cr18Ni10Ti、 00Cr19Ni13Mo3、1Cr13、 2Cr13、 0Cr26Ni5Mo2、 00Cr25Ni7Mo4N、 00Cr22Ni5Mo3N、 00Cr23Ni4MoCuN.   Standard: ASTM A213/A335/A312、 EN10216-2、 GB9948、 GB6479、 GB531 Application :For high temperature and pressure boi ler and petrochem i caI,for example heating-ppel ines,pressure pipel ines, coal-saving devices, […]
February 10, 2018

Low-temperature seamless steel pipe standard

Standard: GB / T 18984-2003 Uses: Applicable -45 ~ -100 ℃ at low temperature pressure vessels and low temperature heat exchanger pipe. Main production steel grade: 09DG, 16MnDG Mechanical behavior: Grade Rm (MPa) ReL (MPa) A (%) Impact test T ( ° C ) Kv (J) 16MnDG 490 ~ 665 ≥ 315 ≥ 30 -45 ≥ 34 10MnDG 400 ≥ 240 ≥ 35 -45 ≥ 34 09D 385 ≥ 240 ≥ 35 -45 ≥ 47 09Mn2VDG 450 ≥ 300 ≥ 30 -70 ≥ 47   chemical composition: Grade C Si Mn P S V 16MnDG 0.12 ~ 0.20 0.20 ~ 0.55 1.20 ~ 1.60 ≤0.025 ≤0.025 ≤0.03 10MnDG ≤0.13 0.17 ~ 0.37 ≤1.35 ≤0.025 […]
December 25, 2017

ASTM A106 PIPE SPECIFICATIONS

A1061/8″ – 26″ Covers SEAMLESS nominal size and wall pipe for high-temperature service, suitable for bending, flanging, and similar forming operations. STD, XS AND XXS ANSI B36.10 Heat treated cold drawn pipe may be furnished to this specification. Optional supplementary requirements may be specified when pipe 8 inch and larger is intended for use where a superior grade is required. Other sizes and dimensions may be furnished Hydrostatic Testing Hydrostatic test pressures are calculated using the Barlow formula. Each pipe shall be tested to 60 percent of specified minimum yield strength, but not exceeding 2500 psi for 3 inch nominal […]
August 7, 2017

ASTM A106 seamless steel pipes,Carbon Seamless Steel Pipe,SMLS Pipe & Tube

ASTM/ASME A106/SA106 seamless carbon steel pipe is used in industrial applications involving high heat, including process piping, boiling plants, compression stations and refineries. ASTM Specification A106 covers seamless carbon steel nominal wall pipe for high-temperature service, suitable for bending, flanging and similar forming operations. NPS 1-1/2 and under may be either hot finished or cold drawn. NPS 2 and larger shall be hot finished unless otherwise specified. Surface finish standards are outlined in the specification. Classification of carbon seamless steel pipe Types Application Structure Purposes General structure and mechanical Low and Medium Pressure Steam and boiler manufacturing Liquid Services Petroleum, […]
May 15, 2017

high pressure JIS G 3454 Seamless Carbon Steel Pipe

JIS G3454 carbon steel pipes are used for pressure conditions at an limited maximum temperature of 350℃. If you requires for higher pressure pipes shall consider JIS G 3455 standard. JIS G3454 Steel pipe can be manufactured into seamless steel pipe or electric-resistance welded steel tubes, the purchaser may designate the quality requirements on hot finished or cold finished state. Surface Treatment: Oiling/Black painting/Varnish/Passivation/Phosphating/Pickling Ends: BE/PE, ends caps Marking: as per requirement Delivery Condition: Annealed/Normalized/Tempered Size:(mm) OD: 12 – 127mm WT: 1 – 12mm or as per customer’s requirement Length: ≤16m. Fixed Length (6m,9m,12m, 16m or as per requirement) or […]
March 10, 2017

JIS G3454 STPG370 Carbon steel pipes for high pressure and temperature

JIS G3454 Grade STPG 370 Specification Covers Carbon Steel Pipes for Pressure Service. Mechanical properties of This steel grades can be varied greatly by heat treating. Through a controlled cycle of heating and cooling, certain desired properties are obtained by producing predictable changes in the microstructure of the steel. Chemical Compositions(%) of JIS G3454 Standard Grade C Si Mn P S JIS G3454 STPG370 ≤0.25 ≤0.35 0.30-0.90 ≤0.040 ≤0.040 STPG410 ≤0.30 ≤0.35 0.30-1.00 ≤0.040 ≤0.040 Mechanical Properties of JIS G3454 Standard Grade Yield Strength (Mpa) Tensile Strength (Mpa) Elongation (%) JIS G3454 STPG370 ≥216 ≥370 ≥30 STPG410 ≥245 ≥410 ≥25 […]
February 21, 2017

API5L JIS G 3454 STPG 370 Carbon steel pipes for high pressure and temperature

JIS G3454 carbon steel pipes are utilized for pressure conditions at a limited optimum temperature of 350 ℃. If you needs for higher pressure pipelines shall think about JIS G 3455 requirement. JIS G3454 Steel pipe can be manufactured into seamless steel pipe or electric-resistance bonded steel tubes, the purchaser might designate the quality requirements on hot ended up or cold completed state. Size (mm): Outer Dimensions: 19.05mm- 114.3mm Wall Thickness:2.0mm -14 mm Length: max 16000mm Chemical Compositions(%) of JIS G3454 Standard Grade C Si Mn P S JIS G3454 STPG370 ≤0.25 ≤0.35 0.30-0.90 ≤0.040 ≤0.040 STPG410 ≤0.30 ≤0.35 0.30-1.00 […]
February 5, 2017

ASTM A106 GR.B,Sch40 seamless steel pipe

ASTM A106 pipe (also covered in ASME specifications as S/A 106) is the standard specification for seamless carbon steel pipe for high-temperature service. Most common uses are in refineries and plants when gasses or fluids are transported at high temperatures and pressures. Process Killed steel, with primary melting process being open-hearth, basic-oxygen, or electric-furnace, possibly combined with separate degassing or refining. Steel cast in ingots or strand cast is permissible. Hot-finished pipe need not be heat treated. Cold-drawn pipe shall be heat treated after the final cold draw pass. ASTM A106 SCH40 Seamless Steel Pipes(OD,WT,WEIGHT PER METER) ASTM A106 SCH40 Seamless Carbon Steel Pipes N Size […]
January 1, 2017

EN 10216-2 Seamless steel tubes, hot rolled boiler tubes

Boiler tubes are used in heat exchange appliances in which the energy is transferred from one medium to the other. The pipes are manufactured from carbon and low-alloy steel grades which are resistant to loads under high pressure and temperatures. They are used for the construction of power engineering appliances such as: boilers, heating coils, stoves, heaters, heat exchangers. Grade and Chemical Composition (%) Grade C≤ Mn P≤ S≤ Si≥ Cr≤ Cu≤ Mo≤ Ni≤ V≤ A106A 0.25 0.27-0.93 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 A106B 0.30 0.29-1.06 0.035 0.035 0.10 0.40 0.40 0.15 0.40 0.08 A106C 0.35 0.29-1.06 […]
November 14, 2016

ASTM A106, Gr.B seamless steel pipe,SCH40,OD 355.6mm, WT11.13mm

seamless steel pipe is used for the mechanical structure, hydraulic equipment ,which is have precision size ,good surface finish.It can greatly reduce mechanical processing hour and improve material utilization, and to improve the quality of products. High quality of cold draw seamless pipe line are mainly use the 10# 20#.In addition to ensure chemical composition and mechanical properties,it will check by Hydro static test,crimping,flared and Squashed test. quality standard of seamless steel pipe API Standard: API 5L Line Pipe for pipeline transportation systems API 5CT Tubing tubing for wells  API 5CT Casing casing for wells  API 5DP Drill Pipe for well drilling   parameter of  ASTM […]
November 3, 2016

ASTM A335 alloy seamless steel pipe Gr. P22, 3 inch SCH 120

We are among the leading Manufacturers, Supplier and Exporters of ASTM A335 P22 Alloy Steel Seamless Pipes that is utilizing high quality raw products. All products are industry-standard complying with or going beyond API, ASTM, ASME, ANSI and other national and global requirements. These pipelines are offered in different size, spec, grades & thickness according to the clients requirements. These pipelines are extensively used in different numerous application such as oil & gas, power plants, ship structure, heavy engineering industries etc. We provide these Pipe at best effort-able rates to our customers in the market. ASTM A335 specification covers nominal […]
