I would like toy inform you that we need seamless pipe 90 tonnage per year .
Could you check the attached file we need this product with that pacification.
yours sincerely
|
(TUBES Informational) |
|||||||||||||
|
STANDARD |
MECHANICAL CHARACTRISTICS |
CHEMICAL COMPOSIOTION (%) |
External diameter (mm) |
Internal diameter (mm) |
Part name |
||||||||
|
(GRADES) |
Hardness (Hv) |
% A |
Rm |
Re |
p |
S |
Si |
Mn |
C |
||||
|
B535105 TSE-1C-E1 |
min 126 Hv |
Min 12 |
Min 420 Mpa |
Min 350 Mpa |
Max 0.05 |
Max 0.05 |
Max 0.10 |
Max 0.50 |
Max 0.10 |
18 ±0.10 |
+0.07 12 -0.00 |
standard limit |
Front wishbon bush |
|
B535105 TSE-1C-E1 |
min 126 Hv |
Min 26% |
Min 420 Mpa |
Min 350 Mpa |
Max 0.05 |
Max 0.05 |
Max 0.10 |
Max 0.50 |
Max 0.10 |
22±0.10 |
+0.07 18 -0.00 |
standard limit |
reaw wishbon bush |
|
B535105 TSE-1C-E1 |
min 126 Hv |
Min 12 |
Min 420 Mpa |
Min 350 Mpa |
Max 0.05 |
Max 0.05 |
Max 0.10 |
Max 0.50 |
Max 0.10 |
35 ±0.10 |
+0.084 29.88 -0.00 |
standard limit |
Assy Anti torque link 405&BE |
|
201420 |
min 160 Hv |
— |
— |
— |
Max 0.30 |
16±0.10 |
+0.2 10.01 -0.00 |
standard limit |
Assy Anti torque link BE |
||||
|
201420 |
min 160 Hv |
— |
— |
— |
Max 0.3 |
16±0.1 |
+0.07 12 -0.00 |
standard limit |
Assy Anti torque link 405 |
||||
|
B535360 TUE-AF56-E1 |
200-235 Hv |
Min 10% |
660-780 Mpa |
Min450 Mpa |
Max 0.04 |
0.02-0.04 |
0.1-0.4 |
0.5-0.8 |
0.3-0.4 |
16±0.1 |
+0.07 12 -0.00 |
standard limit |
Complete Link ASSED |
|
Al:0.02-0.05 |
Cu: Max0.4 |
Ti:Max0.01 |
|||||||||||
|
201420 |
min 160 Hv |
— |
— |
— |
Max 0.3 |
+0.13 30 -0.00 |
27±0.1 |
standard limit |
Assy Anti torque link 405&BE |
||||
