ASTM A335 spec covers small wall and minimum wall smooth terrific alloy-steel pipe (P22 Alloy Pipe) planned for high temperature level service.
We are maker of ASTM A53 Gr B Pipe. We can produce ASTM A53 Grade B Pipe dimensions from 1 inch to 26 inch, ERW welded carbon steel pipe. ASTM A53 seamless pipes is not our advantage, but our A53 Grade steel pipe is in greater quality than seamless pipelines and the ASTM A53B pipe rate is great. You can send your third party pipe inspector to examine the pipe measurements, a53 b pipe equivalent, a53 grade b properties and chemical composition.
| Product Name | ASTM A53 Steel Pipe OD 219.1mm SCH 40 Grade A, Grade B |
| ASTM A53 Steel Diameter | 16 inch / 406.4mm |
| Diameter Tolerance | acc. to ASTM A53, +/-1% of outside diameter |
| Wall Thickness | STD, SCH 40, SCH 60, SCH 80, SCH 120, SCH 160 etc |
| Wall Thickness Tolerance | acc. to ASTM A53, +/- 12.5%t |
| Pipe Standard | ASTM A53, API 5L CSA Z245, A106, ASTM A252, AS 1163, IPS 190 etc |
| A53 Steel Properties Grade | Grade A, Grade B or other steel grade required |
| A53 Steel Properties Test | Hydro test, UT test, Flatten test, Impact test, DWT test if agreed etc |
| Hydro test pressure | As per ASTM A53 |
| Length | SRL, DRL, Random length from 3m to 18m |
| End Finish | Bevelled ends with caps or steel protector |
| Pipe Coating | Black painting, varnish, anti rust oil, FBE, 3PE, 3 layer PE, 3PP etc. |
Varieties
| Processing | Cylinder diameter | Length | Straightness | Dimensional accuracy | Wall thickness | Inner hole roughness |
| cold drawn | 48~325 | ≤ 12m | 0.3~0.8mm/m | ±10% | 0.8~1.6µm | |
| honing | 48~325 | ≤ 10m | 0.3~0.8mm/m | H8~H9 | ±10% | 0.3~0.8µm |
| rolling | 50~250 | ≤ 9m | 0.3~0.8mm/m | H7~H9 | ±10% | 0.01µm |
Mechanical Properties
| Material | Tensile strength | Yield strength | Elongation | Hardness |
| 20# | 530σbN/mm2 | 505σbs/mm2 | 12σs% | 175HB |
| 45# | 660σbN/mm2 | 630σbs/mm2 | 6σs% | 207HB |
| 16Mn | 595σbN/mm2 | 570σbs/mm2 | 9σs% | 190HB |
| 27SiMn | 840σbN/mm2 |
characteristics
Developed for coiling, bending and flanging, A53 carbon steel pipe is suitable for welding. The grades represent specific chemical and mechanical homes and must be kept in mind in choice.
standard:
API5L , ASTM A106 Gr.B, ASTM A53 Gr.B, ASTMA179/A192/A213/A210/370WP91,WP11,WP22 GB5310-2009,GB3087-2008,GB6479-2013,GB9948-2013,
GB/T8163-2008, GB8162-2008,GB/T17396-2009
applications:
1. Fluid pipe
2. Power Plant
3. Structure pipe
4. Scaffolding pipe pharmaceutical andship, building etc
5. High and low pressure Boiler tube
6. Seamless pipe/ tube for petroleum breaking
7. Conduit pipe
ADVANTAGES OF Abter Steel
We constantly inspect each pipe to prevent any imperfection, so we promise each pipe has reached the export standard
We are located near the sea port, the freight may be a little lower, so we promise to provide you the very best quote
We have passed ISO 9001:2000 Certificated, so we believe in quality and service
We have a strong performance, so we guarantee to shipment the goods on time
