February 5, 2017ASTM A53 is a carbon steel alloy, used as structural steel or for low-pressure plumbing. The alloy specifications are set by ASTM International, in specification ASTM A53/A53M.
A53 pipe comes in three types and two grades, A53 Type F, which is longitudinally furnace butt welded or continuous welded (Grade A only), A53 Type E, which is longitudinally electric resistance welded (Grades A and B), and A53 Type S, which is seamless pipe, produced by hot working, and possibly cold finishing, the steel (Grades A and B). ASTM A53 pipe is sized according to the nominal pipe size (NPS) system. It is commonly available with national pipe thread ends or with plain cut ends. It can be used for steam, water, and air conveyance. It is also weldable and can be used in structural applications, although ASTM A500 tube, which is available in the same NPS sizes, is sometime preferred.
Abter specializes in ASTM A53 Steel Pipe Spec, our quality is as high as your demand.We provide A53 grade B pipes from pipe size 1 inch to 26 inch. And the length could be single random length or double random length, the longest length we can do is 18 meter for piling pipe applications.
Product Name ASTM A53 Steel Pipe
A53 Steel Pipe Spec Pipe Diameter: 10 inch/219.1
Diameter Tolerance 320.661mm ~ 327.139mm (acc. to ASTM A53, +/-1% of outside diameter))
Wall Thickness: STD, SCH 40, SCH 60, SCH 80, SCH 120, SCH 160 etc
Wall Thickness Tolerance: acc. to ASTM A53, +/- 12.5%t
Pipe Standard: ASTM A53, API 5L, CSA Z245, A106, ASTM A252, AS 1163, IPS 190 etc
A53 Steel Pipe Spec Pipe Grade Grade A, Grade B or other steel grade required
A53 Steel Pipe Spec Pipe Test Hydro test:UT test, Flatten test, Impact test, DWT test if agreed etc
Hydro test pressure: As per ASTM A53 Spec
Length: SRL, DRL, Random length from 3m to 18m
End Finish: Bevelled ends with caps or steel protector
Pipe Coating: Black painting, varnish, anti rust oil,
FBE, 3PE, 3 layer PE, 3PP etc.
Application: Fluid pipe, line pipe, water pipe, structure steel tube, piling pipe,construction pipe, bridge pipe etc.
