Petroleum Cracking Pipe ASTM A335 Gr P5,LENGTH 5-5.8 Mtr -Russian customers

Hello Dear Sir!
Please let me know the possibility of manufacturing of pipes of steel
grade 1Cr5Mo ASTM A335 P5.
Best regards,
Director of “UMTS”, LLC.
Vedernikov Ruslan

      We ask to inform terms of manufacturing and the price for following positions:

  1.  Petroleum Cracking Pipe  ASTM A335 Gr P5   LENGTH 5-5.8 Mtr

Grade

Diametr

Wall thickness

Quantity (tn)

Price for 1 tn Fob Shanghai

1Cr5Mo

273

11

10



1Cr5Mo

273

12

11



1Cr5Mo

325

10

11



1Cr5Mo

325

12

10



1Cr5Mo

426

10

11



1Cr5Mo

426

12

10





What is ASTM A335 P5 Petroleum Cracking Pipe ?

A335/SA335 P5 is a seamless ferritic alloy-steel pipe used for high-temperature applications. These pipes are versatile and can be used to transmit water, oil and natural gas.

Seamless Ferritic Alloy-Steel Pipe for High Temperature Service. This specification covers both nominal and minimum wall thickness.

ABTERSTEE will supply all the Chrome Moly Alloy A335/SA335 Seamless P5 Piping that your company needs. Economic growth in the United States has led to an increased demand for P5 in recent years. We are not only capable of meeting the demand for this P5 high pressure steel pipe, also known as boiler steel pipe, but US Metals can also meet different needs for customized sizes and shapes.

ASTM A335 P5 is the part of ASTM A335, The pipe shall be suitable for bending, flanging, and similar forming operations, and for fusion welding.

The steel material shall conform to chemical composition, tensile property, and hardness requirements. The range of ASTM A335 P5 pipe sizes that may be examined by each method shall be subjected to the limitations in the scope of the respective practice. Each length of pipe shall be subjected to the hydrostatic test. Also, each pipe shall be examined by a non-destructive examination method in accordance to the required practices.

P5 Pipe Chemical Requirements
Carbon – 0.15% max
Manganese – 0.30% – 0.60%
Phosphorus, max – 0.025%
Sulfur, max – 0.025%
Silicon, max – 0.50%
Chromium – 4.00% – 6.00%
Molybdenum – 0.45% – 0.65%
P5 Pipe Specifications
Tensile strength, min, psi, (MPa) – 60,000 (415)
Yield Strength, min, (MPa) – 30,000 (205)

The range of ASTM A335 P5 pipe sizes that may be examined by each method shall be subjected to the limitations in the scope of the respective practice.

Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength, Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.

Surface treatment:

Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting.
Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles or as requested.

Mechanical properties for ASTM A335 P5
PropertiesData
Tensile strength, min, (MPa)415 Mpa
Yield strength, min, (MPa)205 Mpa
Elongation, min, (%), L/T30/20
Material & Manufacture

Pipe may be either hot finished or cold drawn with the finishing heat treatment noted below.

Heat Treatment
  • A / N+T
  • N+T / Q+T
  • N+T
